Dial Caliper Gauges Applied examples


 "PEACOCK" Caliper Gauges are quite useful for such measurements of O.D. or I.D.
 thickness and diameter which appear so difficult to measure.
Examples

Outside measuring (LA) type
Outside measuring (LA) type

Inside measuring (LB) type
Inside measuring (LB) type

Measuring thickness at the back
end of a projecting workpiece
LA-1 - LA-4
LA-13
LA-20 - LA-23

Measuring thickness at the back
end of a projecting workpiece
Dial upward type
LA-5
LA-5S

Measuring thickness of a cup,
hat or helmet
LA type

Measuring thickness or OD in a
narrow, confined place
LA type

Measuring center OD of a boss
LA-11

Floating type: lower contact
point has a flat 10mm diameter
LA-10

Measuring thickness by hurdling
a projecting area
LA type

Measuring thickness by hurdling
a projecting area
LA-8


Measuring thickness of a large
workpiece or part.
(A): workpiece sizes up to
500mm are accessible (LA-24).

Measuring thickness or OD in a
narrow, confined place
LA-9
LA-11

Measuring ID or groove width
LB-1 - LB-6


Measuring ID of a very shallow
hole
(A): approximately 2mm lip is
sufficient iLB-7V)

Measuring ID or an O-ring
groove
LB-1 - LB-6

Measuring ID by straddling the
center boss
LB-7
LB-14
  Dial Calipers LA series (Outside measuring of ODs and thicknesses)
  Dial Calipers LB series (Inside measuring of ID and groove widths)
